IWE COMPACT RANGE

  • Manufactured in the UK
  • Unbeatable Recovery & Efficiency
  • 316 Stainless Steel Frame & Pipework
  • Fully Programmable
  • 2 Line LED Display
  • Customisable Colour and Logo
  • Stainless Solenoids and Control Valves
  • Stainless Membrane Housings
  • Stainless Inlet Filter
  • Fully Factory Tested
  • P65 Rated
  • Compatible with One Flow Technology
Compact Reverse Osmosis Water Filter
Add to Wishlist
Quick View

Reverse Osmosis - Compact Range

IWE Compact – 150 lph

£2,284.80 - £1,904.00 (exc. VAT)
Permeate flow ratel/h150
Min. salt rejection%95
Recovery%Up to 80
Operating pressurebar10.0
Membrane element / number4021/1
VoltageV/Hz230/50
Motor powerkW0.4
Pre-fusingA2.5
Feedwater connectionR¾'' AG
Permeate/concentrate connectionDN10
Conductivity rangeμS/cm1 – 99
Min. / max. feed water pressurebar3 / 6
Min. / max. feed water temp°C5 / 35
Max. ambient temperature°C40
pH3 – 11
Heightmm370
Widthmm800
Depthmm370
Weight approxca. kg31

IWE Reverse Osmosis Range

Industrial Water Equipment now manufacture a brand new range of Reverse Osmosis Systems. Each unit is manufactured and tested in our new factory in Matlock, Derbyshire.

All of our units are fully bespoke with choices of colour and inclusion of your own logo. Utilising only the best materials such as 316 stainless steel and Grundfos pumps, we believe they are the best engineered and most efficient Reverse Osmosis Systems available on the market.

Need Help?

Unsure if reverse osmosis filtration is suitable for your requirements?

Contact our technical team for advice :

01629 55839

we are more than happy to help.



TECHNICAL DATA
Permeate flow ratel/h150
Min. salt rejection%95
Recovery%Up to 80
Operating pressurebar10.0
Membrane element / number4021/1
VoltageV/Hz230/50
Motor powerkW0.4
Pre-fusingA2.5
Feedwater connectionR¾'' AG
Permeate/concentrate connectionDN10
Conductivity rangeμS/cm1 – 99
Min. / max. feed water pressurebar3 / 6
Min. / max. feed water temp°C5 / 35
Max. ambient temperature°C40
pH3 – 11
Heightmm370
Widthmm800
Depthmm370
Weight approxca. kg31
Permeate flow ratel/h150
Min. salt rejection%95
Recovery%Up to 80
Operating pressurebar10.0
Membrane element / number4021/1
VoltageV/Hz230/50
Motor powerkW0.4
Pre-fusingA2.5
Feedwater connectionR¾'' AG
Permeate/concentrate connectionDN10
Conductivity rangeμS/cm1 – 99
Min. / max. feed water pressurebar3 / 6
Min. / max. feed water temp°C5 / 35
Max. ambient temperature°C40
pH3 – 11
Heightmm1600
Widthmm1200
Depthmm1000
Weight approxca. kg480
IWE Pro Range Reverse Osmosis Water FilterPro 300Pro 600Pro 900Pro 1200Pro 1500
Permeate flow ratel/h30060090012001500
Min. salt rejection%9797979797
Recovery%7575757575
Operating pressurebar1414121110
Membrane element / number4040 / 14040 / 24040 / 34040 / 44040 / 5
VoltageV/Hz2402403 x 400/503 x 400/503 x 400/50
Motor powerkW1.51.51.52.22.2
Pre-fusingA1313161616
Feedwater connectionR2020202020
Permeate/concentrate connectionDN2020202020
Conductivity rangeμS/cm2 – 2002 – 2002 – 2002 – 2002 – 200
Min. / max. feed water pressurebar2 / 62 / 62 / 62 / 62 / 6
Min. / max. feed water temp°C5 / 355 / 355 / 355 / 355 / 35
Max. ambient temperature°C4040404040
pH3 – 113 – 113 – 113 – 113 – 11
Heightmm16501650165016501650
Widthmm500500660660660
Depthmm500500690690690
Weight approxca. kg135135150180195
IWE Promax Range Reverse Osmosis Water FilterPromax 2000Promax 2500Promax 3000Promax 3500
Permeate flow ratel/h2000250030003500
Min. salt rejection%97979797
Recovery%80808080
Operating pressurebar14141414
Membrane element / number4040 / 64040 / 84040 / 104040 / 12
VoltageV/Hz3 x 400/503 x 400/503 x 400/503 x 400/50
Motor powerkW4.04.04.04.0
Pre-fusingA20202020
Feedwater connectionR32323232
Permeate/concentrate connectionDN32323232
Conductivity rangeμS/cm2 – 2002 – 2002 – 2002 – 200
Min. / max. feed water pressurebar2 / 62 / 62 / 62 / 6
Min. / max. feed water temp°C5 / 355 / 355 / 355 / 35
Max. ambient temperature°C40404040
pH3 – 113 – 113 – 113 – 11
Heightmm1750175017501750
Widthmm2500250025002500
Depthmm700700700700
Weight approxca. kg800850900950
IWE Promax Range Reverse Osmosis Water FilterPromax 8 4300Promax 8 5400Promax 8 7000Promax 8 8000Promax 8 9500Promax 8 12000
Permeate flow ratel/h4300540070008000950012000
Min. salt rejection%979797979797
Recovery%75 - 8075 - 8075 - 8075 - 8075 - 8075 - 80
Operating pressurebar13.513.013.513.013.512.5
Membrane element / number8040 /38040 /48040 /58040 /68040 /78040 /9
VoltageV/Hz3 x 400/503 x 400/503 x 400/503 x 400/503 x 400/503 x 400/50
Motor powerkW5.55.57.5111111
Pre-fusingA161620252525
Feedwater connectionR404040505050
Permeate/concentrate connectionDN404040505050
Conductivity rangeμS/cm1 – 2001 – 2001 – 2001 – 2001 – 2001 – 200
Min. / max. feed water pressurebar2 / 72 / 72 / 72 / 72 / 72 / 7
Min. / max. feed water temp°C5 / 355 / 355 / 355 / 355 / 355 / 35
Max. ambient temperature°C454545454545
pH3 – 123 – 123 – 123 – 123 – 123 – 12
Heightmm180018001800180018001800
Widthmm260026002600260026002600
Depthmm850850850850850850
Weight approxca. kg500550650750850950
OPTIONAL EXTRAS
  • Power Saving
  • Grundfos Inverters
  • SMS Compatible
Reverse Osmosis Optional Extras
  • Sealed Unit
  • Leak Detection
  • Auto Shut Off
  • SMS Compatible
Reverse Osmosis - Bunded with leak detection
  • Manufactured in the UK
  • In built level switches
  • 100 Ltr Capacity
  • Start / Stop Signal
  • Interfaces directly with RO
  • Stainless Steel Skid Option
Featuring Grundfos Smart Digital Pump
