clack simplex ws2 water softeners

WS2 Meter Controlled Product Table

Meter controlled systems are more technically advanced. They calculate the permeate flow and from that, determine when to initiate the regeneration process according to your pre entered specifications.

Once the permeate flow has hit the predetermined threshold, the regeneration cycle will ensue triggering the bypass valve. Once the system is in the regeneration cycle, hard water will be made available.

RefDescriptionTank SizeResin QuantityFlow Rate* Capacity @ 300 ppm** Salt Usage Per Regen
SS250-C2250 Litre, WS2 Metered Softener21” x 60”250 Litres10.0 m3/hr41.66 m330.0 kg
SS350-C2350 Litre, WS2 Metered Softener24” x 69”350 Litres14.0 m3/hr58.33 m342.0 kg
SS500-C2500 Litre, WS2 Metered Softener30” x 72”500 Litres20.0 m3/hr83.33 m360.0 kg
SS700-C2700 Litre, WS2 Metered Softener36” x 72”700 Litres26.0 m3/hr116.66 m384.0 kg
* Capacity based on 50g CaCO3 hardness removed per litre of resin
** Salt usage based on 120g per litre of resin. This will increase if salt dosage is increased

Simplex Softeners Explained

Simplex Water Softeners are best used suited to applications where soft water is not required 24 hours a day. Utilising a single vessel hard water will pass to service when the system goes into regeneration.

Need Help?

Unsure which water softener will best suit your requirements? Please contact us on 01629 363311

we are more than happy to help.
