A
Self-Priming Centrifugal Pumps with open impeller
FLOW
3.6 / 66 mc/h
HEAD
3.3 / 33.6 m
POWER
0.55 / 7.5 kW
Construction: Close-coupled centrifugal pumps with open impeller.
The built-in backflow preventer avoids reverse siphoning when the pump is stopped and assures automatic re-priming at the next start.
The pump re-primes itself even if partially filled with liquid and with completely empty suction pipe.
A: version with pump casing and lanter bracket in cast iron.
B-A: version with pump casing and lanter bracket in bronze (the pumps are supplied fully painted).
TECHNICAL DATA
– For clean or slightly dirty water, also with solids up to 10 mm grain size for A 40, A 50 and 15 mm for A 65, A 80.
– For draining a basin or a sump.
– For irrigation. For civil and industrial applications.
CA
Self-Priming Liquid Ring Pumps
FLOW
0.12 / 2.4 mc/h
HEAD
6.5 / 53 m
POWER
0.15 / 0.75 kW
Construction : Close-coupled self-priming liquid ring pumps with star impeller.
CA: version with pump casing and lanter bracket in cast iron.
B-CA: version with pump casing and lanter bracket in bronze (the pumps are supplied fully painted).
TECHNICAL DATA
– For clean liquids without abrasives, without suspended solids, non-explosive, non-aggressive for the pump materials.
– If the liquid to be pumped has entrained air or gas or the flow in the suction pipe is not stable.
– For drawing water out of a well.
– For increasing network pressure (follow local specifications).
NGL
Self-Priming Pumps
FLOW
0.3 / 8.4 mc/h
HEAD
18 / 55.5 m
POWER
0.45 / 1.5 kW
Construction : Close-coupled self-priming shallow-well pump with built-in ejector.
TECHNICAL DATA
– For drawing water out of a well.
– For lifting water containing air or other gases.
– For increasing water pressure from flooded suction applications.
– As pressure boosting pump for central water systems with low pressure (follow local specifications if increasing network pressure).
– For garden use.
– For washing with a jet of water.
NGX
Self-Priming Pumps
FLOW
0.3 / 8.4 mc/h
HEAD
18 / 55.5 m
POWER
0.45 / 1.5 kW
Construction : Close-coupled self-priming shallow-well pump with built-in ejector.
A high-quality pump for domestic water supply. Designed with environmental considerations, featuring a stainless steel casing, brass alloy impeller with minimal use of plastic materials.
TECHNICAL DATA
– For drawing water out of a well.
– For lifting water containing air or other gases.
– For increasing water pressure from flooded suction applications.
– As pressure boosting pump for central water systems with low pressure (follow local specifications if increasing network pressure).
– For garden use.
– For washing with a jet of water.
NG
Self-Priming Pumps
FLOW
0.25 / 9.5 mc/h
HEAD
15.5 / 74.5 m
POWER
0.55 / 22 kW
Construction : Close-coupled self-priming shallow well jet pumps with built-in ejector.
NG: version with pump casing and lanter bracket in cast iron.
B-NG: version with pump casing and lanter bracket in bronze (the pumps are supplied fully painted).
TECHNICAL DATA
– For drawing water out of a well.
– As pressure boosting pump for central water systems with low pressure (follow local specifications if increasing network pressure).
– For clean liquids or slightly dirty surface water.
– For garden use.
– For washing with a jet of water.
MXA
Multi-Stage Self-Priming Pumps
FLOW
1 / 8 mc/h
HEAD
14 / 51 m
POWER
0.45 / 1.1 kW
Construction : Horizontal multi-stage, self-priming, close coupled pump.
Single-piece barrel casing in chrome-nickel stainless steel, with front suction port above pumps axis and radial delivery at top.
Stages in Noryl.
TECHNICAL DATA
– For water supply.
– For domestic use, for garden use and irrigation.
